Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 3 | HVAC AIRCON WATER HOSE 333/T3120 | 1 | $29.97 | |||
| 4 | (W) CLIP - WORMDRIVE 16/27mm(KANBAN) 2201/0005 | 1 | $5.10 | |||
| 5 | CAP-SCREW M_8 L-_25mm 1391/3307D | 1 | $3.61 | |||
| 6 | HOSE CONNECTOR (P564) RE-INST 141/00953 650/10166 | 1 | $15.21 | |||
| 7 | HEATER HOSE 332/T9000 | 1 | $9.28 | |||
| 8 | WATER HOSE- ELBOW 834/10329 | 1 | $71.14 | |||
| 9 | ADAPTER JHN0158 | 1 | $51.19 | |||
| 10 | P-CLIP 821/00412 | 1 | $6.79 | |||
| 11 | SET-SCREW M_8 L-_16mm 1315/0303D | 1 | $0.86 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 13 | SLEEVING - POLY 43.5mmx65 647/10101 | 1 | $20.04 | |||
| 14 | SPACER 823/10809 | 1 | $2.78 | |||
| 15 | WASHER M_5 PLAIN 1420/0005D | 1 | $2.99 | |||
| 16 | SET-SCREW M_5 L-_25mm 1315/0107D | 1 | $20.01 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-C3-4-6-398126-12112358 C3-4-6 HEATER/AIR CON ASSEMBLY AIRCON KIT
View Diagram -
DIAG-C3-4-10-398126 C3-4-10 HEATER/AIR CON ASSEMBLY COMPONENTS 333/T4670
View Diagram -
DIAG-C3-6-1-398126 C3-6-1 IMMOBILISER (KEY)
View Diagram
