Kubota M5N-091HD24 C22002 DAMPER DISK Parts Diagram
Exploded-view parts diagram "C22002 DAMPER DISK" for the Kubota M5N-091HD24, Kubota M5N-091HDC24, Kubota M5N-091HDRC24, Kubota M5N-111HD24, Kubota M5N-111HDC24 and Kubota M5N-111HDRC24. 3 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY DAMPER 3A091-25130 3C291-25130 | 1 | $1,038.55 | |||
| 020 | PIN 05012-01018 | 1 | $1.51 | |||
| 030 | Bolt - M10 x 1.25 x 20mm 01135-51020 | 1 | $1.99 | |||
Showing 1 to 3 of 3 parts
