Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| GROMMET BLIND 7.95 DIA x 3.5 THK 2410/1106 | 1 | $4.08 | ||||
| NUT CAP M8 335/E1356 | 1 | $0.27 | ||||
| 1 | WORKLAMP 12V 700/50091 | 1 | $81.21 | |||
| 3 | BULB H3 12V 55W 720/10061 | 1 | $8.39 | |||
| 4 | SPRING 700/10103 | 1 | $0.81 | |||
| 5 | WORK LAMP BRK 123/06305 | 1 | $6.76 | |||
| 7 | SPRING WASHER M8 1425/0007D | 1 | $1.52 | |||
| 8 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.00 | |||
| 9 | SET-SCREW M_8 L-25mm 1315/0307 1315/0307Z | 1 | $0.37 | |||
| 10 | SET-SCREW M_6 L-_25mm 1315/0207Z 1315/0207D | 1 | $2.40 | |||
| 11 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.17 | |||
| 12 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $6.15 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-C1-4-5-400577 C1-4-5 LIGHT WORKING INSTALLATION
View Diagram -
DIAG-C1-4-1-400577-12836800 C1-4-1 LIGHT,WORKING .
View Diagram -
DIAG-C1-4-10-400577 C1-4-10 NO LIGHTS
View Diagram
