C1-19-3 SWITCH HYDRAULIC OIL TEMP. Parts Diagram | JCB | Scholten’s Equipment

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
1	ADPT HYD OIL TEMP SWITCH 816/25056	1	AVAILABLE TO ORDER	$12.55	Quantity
1A	O-RING 2401/0508	1	8 IN STOCK	$3.28	Quantity
2	WATER TEMP SWITCH 701/37400	1	AVAILABLE TO ORDER	$150.80	Quantity
3	WASHER BONDED 3/8" BSP(KANBAN) 1406/0015	1	18 IN STOCK	$1.52	Quantity

Showing 1 to 4 of 4 parts
