Kubota M7-151PB KVT B85002 ELECTRICAL WIRING (FRONT PILLAR) [NEW] ## S.No.;>=10375 Parts Diagram

Exploded-view parts diagram "B85002 ELECTRICAL WIRING (FRONT PILLAR) [NEW] ## S.No.;>=10375" for the Kubota M7-151PB KVT. 4 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
BOLT 01010-00812 01053-50812 1 4 IN STOCK $1.34
CLIP T1060-30550 1 AVAILABLE TO ORDER $10.08
Plain Washer (Flat Washer) 04015-50080 1 1 IN STOCK $0.36
W/H(A-PILLAR) 3J030-68613 3J080-15820 1 AVAILABLE TO ORDER $546.46

Showing 1 to 4 of 4 parts

  • DIAG-B85001-125485 B85001 ELECTRICAL WIRING (FRONT PILLAR) [OLD] ## S.No.;<=10374

    View Diagram
  • DIAG-B85500-125485 B85500 ELECTRICAL WIRING (ROOF)

    View Diagram
  • DIAG-B81500-125485 B81500 ELECTRICAL WIRING (CAB) 4 (AIR CONDITIONER)

    View Diagram
