| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | M/Cd K/POST CARRIAGE p/slide 589/10275 | 1 | $10,252.84 | |||
| 2 | LINER BEARING 70x84x57 808/00396 831/10211 | 1 | $123.91 | |||
| 3 | BI-METALLIC BEARING 90/80 x 34 808/00388 332/G0942 | 1 | $78.79 | |||
| 4 | BLANKING DISC 123/05228 | 1 | $91.76 | |||
| 5 | SEAL 123/04237 | 1 | $36.36 | |||
| 6 | SEAL 813/00456 | 1 | $55.15 | |||
| 7 | CLAMP BOLT 1.5UNFx205 826/11235 | 1 | $159.78 | |||
| 8 | CLAMP PLATE 331/56478 | 1 | $44.72 | |||
| 10 | L/H TAB WASHER 823/10331 | 1 | $6.32 | |||
| 10 | R/H TAB WASHER 823/10332 | 1 | $6.32 | |||
| 11 | NUT 826/00820 | 1 | $55.66 | |||
| 12 | WEAR SLIDER top 332/D1432 | 1 | $228.89 | |||
| 14 | WEAR SLIDER bottom 332/D1433 | 1 | $234.15 | |||
| 16 | BLOCK SLIDE BOTTOM 123/08030 | 1 | $225.55 | |||
| 17 | SPACER 123/08025 | 1 | $151.98 | |||
| 18 | GREASE NIPPLE 1450/1007 | 1 | $7.33 | |||
| 18 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
| 19 | ADAPTOR 816/25038 816/90892 | 1 | $14.89 | |||
Showing 1 to 18 of 18 parts
