Kubota SVL65-2 B35500 STARTER [COMPONENT PARTS] Parts Diagram
Exploded-view parts diagram "B35500 STARTER [COMPONENT PARTS]" for the Kubota SVL65-2 and Kubota SVL65-2C. 29 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY STARTER 1J730-63010 | 1 | $334.60 | |||
| 010 | STARTER, ASSY 1J740-63010 | 1 | $551.61 | |||
| 020 | YOKE 17123-63080 | 1 | $451.03 | |||
| 040 | ARMATURE 1J740-63070 | 1 | $805.07 | |||
| 040 | ARMATURE 17123-63070 | 1 | $887.65 | |||
| 050 | BEARING, BALL 17123-63500 | 1 | $36.49 | |||
| 060 | BRG BALL RADIAL1 11460-63500 | 1 | $28.79 | |||
| 070 | CLUTCH, OVER RUN 1J730-63040 | 1 | $949.92 | |||
| 090 | ROLLER 19212-63100 | 1 | $2.37 | |||
| 100 | RETAINER 11460-63110 | 1 | $9.19 | |||
| 110 | GEAR 1J740-63270 | 1 | $39.41 | |||
| 110 | GEAR (2) 11460-63270 | 1 | $57.90 | |||
| 120 | GEAR, 1 17123-63260 | 1 | $41.46 | |||
| 130 | FRAME, DRIVE END 17123-63030 | 1 | $166.41 | |||
| 140 | FRAME, END 1J730-63200 | 1 | $159.59 | |||
| 160 | HOLDER, BRUSH 17123-63380 | 1 | $127.01 | |||
| 160 | HOLDER,BRUSH 17123-63382 Discontinued | 1 | $112.27 | |||
| 170 | SPRING 17123-63140 | 1 | $14.65 | |||
| 180 | ASSY SWITCH, MAG 1J730-63020 | 1 | $721.58 | |||
| 190 | SCREW 17123-93310 | 1 | $5.43 | |||
| 200 | SCREW 17123-93320 | 1 | $5.43 | |||
| 210 | BOLT 17123-63320 | 1 | $21.66 | |||
| 220 | BALL, STEEL 15521-97131 19212-97130 | 1 | $1.45 | |||
| 230 | SPRING 11460-63120 | 1 | $9.25 | |||
| 240 | O-RING 1J740-96660 | 1 | $16.98 | |||
| 240 | O-RING 15511-96660 | 1 | $20.24 | |||
| 250 | PIPE, DRAIN 15833-63570 | 1 | $21.64 | |||
| 260 | NUT, HEX 13963-92010 | 1 | $5.94 | |||
| 270 | NUT 16285-92010 | 1 | $8.40 | |||
Showing 1 to 29 of 29 parts
