Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | P/PIN 63.45/63.37x600 811/90144 | 1 | $539.35 | |||
| 2 | P/PIN 49.92/49.82 * 254 403/H0048 332/G3681 | 1 | $172.54 | |||
| 3 | P/PIN 49.95/49.85 * 396 403/C7146 811/50428 | 1 | $570.09 | |||
| 4 | P/PIN 50.80/50/70 * 537 403/H0085 1021/2077 403/G1191 | 1 | $602.45 | |||
| 6 | PIN PIVOT 811/50560 | 1 | $295.70 | |||
| 7 | P/PIN 63.45/63.41x367 811/50507 | 1 | $492.74 | |||
| 8 | PIN PIVOT 911/32400 | 1 | $354.54 | |||
| 11 | P/PIN 44.95/44.85 * 239 403/C8276 811/70088 | 1 | $142.31 | |||
| 15 | SPACER 162/02338 334/G6204 | 1 | $18.58 | |||
| 16 | PIVOT PIN RETAINER (FINISH NONE) 162/00525 332/H6616 | 1 | $2.18 | |||
| 17 | CAP SCREW M8 x 16 G12.9 MICRO-EN 1392/3303D | 1 | $29.14 | |||
| 18 | Nut M12 STD SELF LOCK 1370/0403D | 1 | $2.11 | |||
| 19 | BOLT M12 L-_60mm 1315/3514D | 1 | $3.30 | |||
| 20 | BOLT M12x100 1315/3520D | 1 | $2.94 | |||
| 21 | BOLT 1315/3825D | 1 | $39.57 | |||
| 23 | WASHER M12 PLAIN 1420/0009D | 1 | $0.00 | |||
| 24 | BOLT M12x110 1315/3521D | 1 | $4.63 | |||
| 27 | WA PIVOT PIN 63.45/63.37 403/F5087 | 1 | $787.70 | |||
| 29 | BOSS 25 OD X 17 ID 829/00570 | 1 | $56.52 | |||
| 30 | BOLT M16 X 50 TUFLOK 826/01730 | 1 | $40.57 | |||
| 31 | M12 X 35 SET SCREW 10.9 826/01702 | 1 | $14.07 | |||
| 32 | P/PIN 49.97/49.92x221 811/90125 | 1 | $179.36 | |||
| 33 | PIVOT PIN WA 911/33000 | 1 | $319.87 | |||
| 34 | KEEP PLATE SPACER 335/F0241 | 1 | $4.62 | |||
| 35 | SHIM 101 X 64 X 1.6 332/D8259 | 1 | $12.91 | |||
| 36 | SHIM 1.0mm 823/00237 | 1 | $0.00 | |||
| 37 | PLUG BLANKING 7O DIA 835/00190 | 1 | $44.09 | |||
| 38 | NUT M20 STD SELF LOCK 1370/0703D | 1 | $4.40 | |||
| 39 | WASHER 1/2 LARGE 1412/0005D | 1 | $2.03 | |||
Showing 1 to 29 of 29 parts
Related Assemblies
-
DIAG-B330-10-1-401632 B330-10-1 LOADER PIVOTS PIVOT PINS
View Diagram -
DIAG-B310-100-1-401632 B310-100-1 LOADER ARM/LOADER BOOM WASTEMASTER BOOM GUARD
View Diagram -
DIAG-B330-15-1-401632 B330-15-1 LOADER PIVOTS PIVOT PIN LOCATION
View Diagram
