Kubota B7400HSD B31000 WINKER LAMP Parts Diagram
Exploded-view parts diagram "B31000 WINKER LAMP" for the Kubota B7400HSD, Kubota B7500D and Kubota B7500HSD. 8 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | STAY, HAZARD LIGHT 6C140-54980 | 1 | $7.45 | |||
| 020 | Lamp Assembly (Winker/Rear Lamp) 37410-52290 | 1 | $45.66 | |||
| 030 | ASSY BODY CLEANE 37410-52710 | 1 | $40.04 | |||
| 040 | Bulb 37410-52720 | 1 | $24.71 | |||
| 050 | Turn Signal / Winker Lamp Lens 37410-52730 | 1 | $15.09 | |||
| 060 | GASKET 37410-52740 | 1 | $9.88 | |||
| 070 | Nut 02172-50100 02116-50100 | 1 | $0.36 | |||
| 080 | WASHER, TOOTHED 04411-50100 | 1 | $1.41 | |||
Showing 1 to 8 of 8 parts
