Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | LH SKIRT MOULDING 346/00097 | 1 | $594.34 | |||
| 2 | EXTERNAL FRONT BULKHEAD M 346/00101 | 1 | $513.02 | |||
| 3 | RH SKIRT MOULDING 346/00098 | 1 | $559.19 | |||
| 4 | SCREW M8x20 BUTTON SOCKET 826/01486 | 1 | $1.12 | |||
| 5 | BLACK WASHER M8 823/00529 | 1 | $3.11 | |||
| 6 | SKIRT BRACKET - RH 331/49137 | 1 | $32.06 | |||
| 7 | SKIRT BRACKET - RH FORWAR 331/49139 | 1 | $67.60 | |||
| 8 | SKIRT BRACKET - LH FRONT 331/46835 | 1 | $96.67 | |||
| 9 | SKIRT BRACKET - RH FRONT 331/48780 | 1 | $20.27 | |||
| 10 | SKIRT BRACKET - LH 331/46812 | 1 | $38.14 | |||
| 11 | NUT M_8 BOLHOFF 826/10977 | 1 | $2.14 | |||
| 12 | M8 HEX RIVNUT (P545/220NXG) 826/11387 | 1 | $6.18 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-B290-15-1-404681 B290-15-1 OTHER OPERATOR ENCLOSURE ITEMS CANOPY SWITCH & LIGHT BOX
View Diagram -
DIAG-B290-30-1-404681 B290-30-1 OTHER OPERATOR ENCLOSURE ITEMS NUMBER PLATE MOUNTING
View Diagram -
DIAG-B290-10-1-404681 B290-10-1 OTHER OPERATOR ENCLOSURE ITEMS SWITCH PANEL, LH CONSOLE, CANOPY BUILDS
View Diagram
