Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | FRONT GLASS MTG BKT JCB 400/V7220 | 1 | $1,877.45 | |||
| 2 | HEX.BOLT M10x50 LG 1315/3412Z 1315/3412D | 1 | $5.17 | |||
| 3 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 4 | GLASS FRONT 400/E8646 | 1 | $136.65 | |||
| 5 | FRONT GLASS SEAL 400/K1663 | 1 | $180.58 | |||
| 6 | FRONT GLASS SEAL LOCKING 400/K3974 | 1 | $24.67 | |||
| 7 | EMERGENCY EXIT TAB 400/H7392 | 1 | $33.34 | |||
| 8 | CABLE TIE 120mm 204/07006 | 1 | $1.64 | |||
| 9 | 'WIPER MOTOR 346 12V 105 DEG RH EXC COVE 400/K7289 | 1 | $189.15 | |||
| 10 | WIPER BLADE REAR (P461/RTFL) 334/F6370 | 1 | $20.08 | |||
| 11 | .75MM LONG WIPER ARM OS 334/S7275 | 1 | $75.84 | |||
| 12 | WASHER JET ASSY (Short with elbow) 290/01200 | 1 | $75.68 | |||
| 13 | SWITCH PANEL 12V 3POS 701/E0082 | 1 | $22.22 | |||
| 14 | WASH/WIPE FRONT CAB 721/X1879 | 1 | $89.90 | |||
| 15 | (Pre-P)-SCREEN WASH TUBE 647/02014 | 1 | $15.63 | |||
| 16 | WASH/WIPE FRONT CAB EXT HARNESS 721/X1878 | 1 | $36.61 | |||
| 17 | WIPER MOTOR COVER 400/J2783 | 1 | $69.20 | |||
| 18 | ACTUATOR wiper 701/E8854 | 1 | $3.05 | |||
| 19 | SEAL-EPDM SPONGE CLOSED CELL 3.2m 400/U2481 | 1 | $168.89 | |||
| 21 | WASHER 7/16 LARGE PLAIN 1412/0004Z | 1 | $1.52 | |||
| 22 | SIKA ADHESIVE 552 4103/3200 | 1 | $184.76 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-B250-80-5-395221 B250-80-5 GLASS/FRAMES ,FRONT GLASS TEMPERED - JCB
View Diagram -
DIAG-B250-81-1-395221 B250-81-1 GLASS/FRAMES ,GA FRONT GLASS WITH WIPER SP T4
View Diagram -
DIAG-B250-80-1-395221 B250-80-1 GLASS/FRAMES ,FRONT GLASS TEMPERED - JCB
View Diagram
