| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | MISC FRONT WINDOW UNPROTE 401/V2315 | 1 | $1,644.10 | |||
| 2 | MISC STD SIDE WINDOW (P512B) 400/J8867 | 1 | $802.41 | |||
| 3 | MISC GLASS LH STD OS (P512B) 336/C2671 | 1 | $178.74 | |||
| 4 | MISC ROOF GLASS OS (P511) 400/F0742 | 1 | $373.81 | |||
| 5 | MISC GLASS REAR OS (P512B) 336/A8892 | 1 | $301.72 | |||
| 6 | DECAL: EMERGENCY EXIT - H 817/19457 402/T6290 | 1 | $1.49 | |||
| 7 | Rubber SPACER BLOCK 926/15500 | 1 | $0.20 | |||
| 8 | TEROSON PU 8545 UV BO500ML 4104/4200 4104/4250 | 1 | $125.47 | |||
| 11 | TEROSON PU 8910 CR310ML 4103/5200 4103/5242 | 1 | $30.29 | |||
| 12 | SCREW M6x25 BUTTON SOCKET 826/01768 | 1 | $2.11 | |||
| 16 | M5 NUT - STD FLANGE G8 (TLT) 1370/0008B | 1 | $1.70 | |||
| 17 | MISC NYLON WASHER (NG) 335/D9948 | 1 | $1.20 | |||
| 18 | MISC PIVOT BUSH OS (P512B) 335/G6628 | 1 | $3.06 | |||
| 19 | BOLT FLANGED HEX M8 x 30 g8.8 1317/3308D | 1 | $2.15 | |||
| 20 | MFI WINDOW SUPPORT 331/25735 | 1 | $0.44 | |||
| 21 | SOCKET SCREW M5x15 826/01723 | 1 | $1.43 | |||
| 22 | NUT M6 LOCK + WASHER 1370/0108D | 1 | $1.55 | |||
| 23 | BUFFER M8x65 (P513) 835/10129 | 1 | $107.35 | |||
| 24 | M8 NUT - STD FLANGE G8 1370/0208B | 1 | $1.94 | |||
| 25 | WASHER 5/16 LARGE PLAIN 1412/0002Z 1412/0002D | 1 | $1.92 | |||
| 26 | WASHER M8 HARDENED(KANBAN) 1422/0007Z | 1 | $14.22 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-B250-130-1-397590 B250-130-1 GLASS/FRAMES INSTALLATION STANDARD, PK, OS
View Diagram -
DIAG-B250-140-1-397590 B250-140-1 GLASS/FRAMES GLASS UPPER ASSEMBLY
View Diagram -
DIAG-B250-125-1-397590 B250-125-1 GLASS/FRAMES INSTALLATION STANDARD, PK PROT OS
View Diagram
