Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | (W) (P) DOOR FRAME WA (LH)~3000 332/A0360 | 1 | $6,965.99 | |||
| 2 | CORPORATE LATCH - RH (61.5200.0213) 332/A5005 332/A9117 | 1 | $136.19 | |||
| 3 | DOOR HANDLE - CORPORATE 332/A3730 | 1 | $97.52 | |||
| 4 | (W) (P) (P) DOOR SEAL 4230mm 333/L4252 | 1 | $234.86 | |||
| 5 | (W) (P) HINGE COVER 331/52619 | 1 | $52.92 | |||
| 6 | GASKET-STD DOOR HANDLE 2m 331/28105 333/A6182 | 1 | $7.72 | |||
| 7 | (W) (P) TOP HINGE WA (LH) FASTRAC 335/09904 | 1 | $420.40 | |||
| 8 | BUSH 476/10132 | 1 | $27.84 | |||
| 9 | (W) (P) STRIKER BRACKET FASTRAC 331/58097 | 1 | $76.13 | |||
| 10 | (P) Door Glass (L/H)~FT 3000S 827/80360 | 1 | $877.41 | |||
| 11 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 12 | (W) (P) PLASTIC HINGE MOUNT 331/51442 | 1 | $207.88 | |||
| 13 | G/A DOOR STRIKER 128/12669 | 1 | $126.37 | |||
| 14 | (W) (P) LH MIRROR ARM 331/53516 335/10221 | 1 | $97.76 | |||
| 15 | SCREW SOCKET M8x25 LONG 826/01487 | 1 | $10.21 | |||
| 16 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 17 | SET-SCREW M_6 L-_20mm 1315/0205D | 1 | $0.57 | |||
| 18 | RIVET NUT-M8(KANBAN) 826/01102 | 1 | $4.83 | |||
| 19 | CAP-SCREW M10 L-_25mm GRADE 12.9 1391/3407D | 1 | $2.78 | |||
| 20 | CAPSCREW: M10 x 40 1391/3410D | 1 | $2.23 | |||
| 21 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 22 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 23 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 24 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 25 | Adhesive Kit 993/55700 993/55701 | 1 | $332.68 | |||
| 26 | M8 CSK SOCKET HEAD SCREW 826/10481 | 1 | $2.97 | |||
| 27 | SCREW BUTTON HEAD M8 X30 826/10504 | 1 | $1.46 | |||
| 29 | SPRING WASHER M8 1425/0007D | 1 | $1.52 | |||
| 30 | (W) (P) SPACER 331/54581 | 1 | $2.00 | |||
| 31A | SET-SCREW M_8 L-_20mm 1315/0305D | 1 | $10.29 | |||
| 32 | (W) (P) WA HINGE MOVABLE 332/U7940 | 1 | $204.48 | |||
| 35 | LATCH HANDLE - RH ( 41.5212.1302 ) 826/11628 332/A5708 | 1 | $248.84 | |||
| 36 | RIVET NUT (BR3) 826/01101 | 1 | $3.76 | |||
| 37 | (W) (P) LH DOOR LATCH COVER (TRIM 331/52914 332/A0398 | 1 | $54.33 | |||
| 38 | 'SCREW M6x16 BUTTON SOCKET(KANBAN) (BR3) 826/01413 826/01559 | 1 | $8.07 | |||
| A | '(W) (P) DOOR ASSY AS SUPPLIED(LH)fastra 482/10205 332/U9640 | 1 | $2,511.22 | |||
Showing 1 to 36 of 36 parts
Related Assemblies
-
DIAG-B240-4-1-393600 B240-4-1 DOOR ASSEMBLY RIGHT HAND SIDE
View Diagram -
DIAG-B240-6-1-393600 B240-6-1 DOOR COMPONENTS
View Diagram -
DIAG-B240-3-1-393600 B240-3-1 hinge FITTINGS-LOWER
View Diagram
