Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | GRAMMER ACTIMO XXL 332/W9527 334/R3354 | 1 | $5,378.46 | |||
| 2 | GRAMMER ACTIMO XXL SEAT BASE WA 333/R6429 | 1 | $445.24 | |||
| 3 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 4 | SET-SCREW M10 L-_25mm 1315/0407D | 1 | $0.62 | |||
| 5 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 6 | SET-SCREW M10 L-_20mm 1315/0405D | 1 | $4.43 | |||
| 8 | '(W) (P) SWITCH PANEL 24V 2POS SPCO RW ( 701/E0034 | 1 | $33.28 | |||
| 9 | ACTUATOR ; HEATED SEAT ETCHED 701/E8852 | 1 | $6.97 | |||
| 10 | SEAT LINK HARNESS 334/R5724 | 1 | $219.61 | |||
Showing 1 to 9 of 9 parts
Related Assemblies
-
DIAG-B2-34-87-404999 B2-34-87 SEATS COMPONENTS ACTIMO XXL, BLACK, 334/R3354
View Diagram -
DIAG-C1-0-2-404999 C1-0-2 MAIN ELECTRICS
View Diagram -
DIAG-B1-18-3-404999 B1-18-3 MIRROR REAR VIEW WIDE ANGLE
View Diagram
