Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 3 | ROOF CAB 331/16658 | 1 | $1,672.18 | |||
| 4 | BOLT M10x40 1315/3410Z | 1 | $5.45 | |||
| 5 | WASHER PLAIN 3/8 LARGE1412/0001Z 1412/0003Z | 1 | $1.52 | |||
| 14 | FRONT SKIRT 265/01710 346/00022 | 1 | $271.13 | |||
| 15 | LEFT SKIRT TRIMMING 265/02053 346/00025 | 1 | $687.21 | |||
| 16 | RIGHT SKIRT TRIMMING 331/17583 346/00026 | 1 | $279.45 | |||
| 17 | SCREW M6x25 BUTTON SOCKET 826/01560 | 1 | $4.18 | |||
| 18 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 19 | WASHER 1/4 LARGE PLAIN 1412/0001Z 1412/0001D | 1 | $0.54 | |||
| 20 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 21 | SET-SCREW M_6 L-_20mm(KANBAN) 1315/0205Z | 1 | $0.65 | |||
| 23 | BRACKET MOUNTING 265/02143 | 1 | $11.99 | |||
| 24 | (W) (P) WASHER M20 PLAIN 1420/0012Z | 1 | $2.82 | |||
| 25 | NUT M20 THIN PLAIN 1370/0702Z | 1 | $2.57 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-B2-23-3-404670 B2-23-3 COVER SALES SPECIAL
View Diagram -
DIAG-B2-25-1-404670 B2-25-1 SKIRTS, CANOPY
View Diagram -
DIAG-B2-23-1-404670 B2-23-1 COVER HEATER
View Diagram
