B2-16-1 AIR SUSPENSION SEAT HEATED 24 VOLT-OPTIONAL Parts Diagram | JCB | Scholten’s Equipment

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
3	HARNESS SEAT AND M 721/00510	1	AVAILABLE TO ORDER	$193.56	Quantity
4	(W) (P) SWITCH 24v 701/60031	1	1 IN STOCK	$115.54	Quantity
5	DECAL heated seat switch 701/58715	1	AVAILABLE TO ORDER	$3.30	Quantity
6	Auto Blade Fuse 10A 716/05705	1	AVAILABLE TO ORDER	$0.62	Quantity

Showing 1 to 4 of 4 parts

DIAG-B2-15-1-404670 B2-15-1 SEAT, SUSPENSION KAB/BOSTROM
View Diagram
DIAG-B2-17-1-404670 B2-17-1 AIR SUSPENSION SEAT COMPONENTS
View Diagram
DIAG-B2-12-1-404670 B2-12-1 SUSPENSION SEAT COMPONENTS KAB/BOSTROM
View Diagram

Previous Assembly DIAG-B2-15-1-404670 B2-15-1 SEAT, SUSPENSION KAB/BOSTROM Next Assembly DIAG-B2-17-1-404670 B2-17-1 AIR SUSPENSION SEAT COMPONENTS
