Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA RH STEP FRAME 402/F0676 | 1 | $1,583.71 | |||
| 2 | STEP 540-170 (X-Feed) 331/22800 | 1 | $127.53 | |||
| 3 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 4 | SET-SCREW M10 L-_40mm 1315/0410D | 1 | $2.49 | |||
| 5 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 6 | STEP TREAD 410x180 331/27034 | 1 | $170.48 | |||
| 7 | WASHER 3/8IN LARGE 1412/0003D | 1 | $0.57 | |||
| 8 | SET-SCREW M10 L-_50mm 1315/0412D | 1 | $4.08 | |||
| 9 | FLEXI STEP MOUNTING 334/U0189 | 1 | $133.79 | |||
| 10 | WA RH GRAB RAIL 333/T6787 | 1 | $424.73 | |||
| 11 | WASHER 1/2 LARGE 1412/0005D | 1 | $2.03 | |||
| 12 | WASHER M12 PLAIN 1420/0009D | 1 | $1.07 | |||
| 13 | SET SCREW M12x40 1315/0510D | 1 | $2.86 | |||
| 14 | Nut M12 STD SELF LOCK 1370/0403D | 1 | $1.01 | |||
| 15 | STEP (X-Feed) 589/10221 | 1 | $166.10 | |||
| 16 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 17 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 18 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
Showing 1 to 18 of 18 parts
Related Assemblies
-
DIAG-B190-280-1-404978 B190-280-1 OTHER BODYWORK ITEMS STEP LOW ASSEMBLY RIGHT
View Diagram -
DIAG-B190-275-1-404978 B190-275-1 OTHER BODYWORK ITEMS BATTERY BOX FASTENINGS
View Diagram -
DIAG-B190-270-1-404978 B190-270-1 OTHER BODYWORK ITEMS STEP LOW ASSEMBLY LEFT
View Diagram
