Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | SCR - A052U163 334/T3768 | 1 | $16,053.50 | |||
| 1A | Sensor Temperature 400/03341 | 1 | $1,055.96 | |||
| 2 | DRT A052J812 (was A045W697) 334/T3763 | 1 | $1,720.62 | |||
| 3 | DOC - A048H285 334/T8270 | 1 | $8,633.41 | |||
| 3A | Engine SENSOR,TEMPERATURE 400/02669 | 1 | $1,449.39 | |||
| 4 | T BOLT CLAMP 253DIA 335/F4846 | 1 | $49.89 | |||
| 5 | T BOLT CLAMP 292DIA 335/F4844 | 1 | $78.78 | |||
| 9 | FIR TREE CABLE TIE FIXING(KANBAN) 242/00290 | 1 | $5.06 | |||
| 10 | MISC MOUNT RUBBER PWPK 333/E7256 | 1 | $36.88 | |||
| 11 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 12 | SET-SCREW M_6 L-_20mm 1315/0205D | 1 | $0.57 | |||
| 13 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
| 19 | SET-SCREW M_6 L-_25mm 1315/0207Z 1315/0207D | 1 | $0.33 | |||
| 21 | SPRING WASHER M8 1425/0007D | 1 | $1.52 | |||
| 22 | NUT M_8 STD PLAIN 1370/0201Z 1370/0201D | 1 | $1.07 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-B190-145-1-404637 B190-145-1 OTHER BODYWORK ITEMS ASSEMBLY DEF SYSTEM
View Diagram -
DIAG-B190-155-1-404637 B190-155-1 OTHER BODYWORK ITEMS ASSEMBLY AUXILARY FUEL HOSE GUARD
View Diagram -
DIAG-B190-130-1-404637 B190-130-1 OTHER BODYWORK ITEMS ARTI BUMP STOP-36 DEG
View Diagram
