Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | ABI C/WEIGHT TLT 3/3.5T 400/B6856 | 1 | $7,222.53 | |||
| 2 | WA COUNTERWEIGHT BRACKET 332/V5508 | 1 | $495.36 | |||
| 3 | TOWING PIN.ZINC PLTD. 295/00287 | 1 | $55.51 | |||
| 4 | COUNTERWEIGHT HOLE COVER 826/11703 | 1 | $1.76 | |||
| 5 | WASHER WEDGE 295/00391 | 1 | $211.92 | |||
| 7 | SHIM-1.2MM 191/50002 | 1 | $51.12 | |||
| 8 | R CLIP 821/00514 | 1 | $7.49 | |||
| 9 | SHIM 2.00MM 191/50003 | 1 | $66.23 | |||
| 10 | Bolt M24 x 340 lon 1315/4037D | 1 | $127.14 | |||
| 11 | NUT M24 1370/0903D | 1 | $15.30 | |||
| 12 | WASHER M24 1420/0014D | 1 | $4.62 | |||
| 13 | HEX.BOLT M16x110 LG 1315/3721D | 1 | $24.54 | |||
| 14 | M16 LOCK NUT 1370/0603D | 1 | $21.78 | |||
| 15 | WASHER M16 PLAIN 1420/0011D | 1 | $1.43 | |||
| 18 | SET SCREW M12x45 1315/0511D | 1 | $3.38 | |||
| 19 | Nut M12 STD SELF LOCK 1370/0403D | 1 | $1.01 | |||
| 20 | WASHER M12 PLAIN 1420/0009D | 1 | $1.07 | |||
| 21 | M12X40-C'SK SOCKET HEAD SCREW 826/11454 | 1 | $7.49 | |||
| 22 | 5MM SPACER 123/07745 | 1 | $17.43 | |||
| 23 | SET-SCREW M16 L-_40mm 1315/0710D | 1 | $3.11 | |||
| 24 | THIN NUT M16 1370/0602D | 1 | $1.46 | |||
| 25 | PLATE-SPACER 331/52307 | 1 | $31.14 | |||
| 26 | WASHER 823/00485 | 1 | $18.60 | |||
| 28 | SPRING-WASHER M12 1425/0009Z 1425/0009D | 1 | $0.85 | |||
| 29 | CORNER COVER.RUBBER(EXH) 295/00590 | 1 | $32.09 | |||
| 30 | BOOM END COVER 331/14928 346/00110 | 1 | $384.85 | |||
| 31 | 'SCREW M6x16 BUTTON SOCKET(KANBAN) (BR3) 826/01413 826/01559 | 1 | $8.07 | |||
Showing 1 to 27 of 27 parts
