Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 3 | HARDENED WASHER M24 1422/0014D | 1 | $8.12 | |||
| 4 | BOLT 1316/4034D | 1 | $266.54 | |||
| 5 | NUT 1371/0901D | 1 | $19.00 | |||
| 6 | WASHER-M24, 8 THK 823/10643 | 1 | $140.35 | |||
| 8 | BOLT 1315/4036D | 1 | $172.20 | |||
| 9 | BOLT M24 x 190 1316/4029D | 1 | $81.10 | |||
| 10 | Plug Yellow M30 835/00170 | 1 | $14.41 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 13 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
Showing 1 to 9 of 9 parts
Related Assemblies
-
DIAG-B170-10-1-404775 B170-10-1 BONNET/ ENGINE COVERS/ GRILLES CLOSING PANELS
View Diagram -
DIAG-B180-5-1-404775 B180-5-1 COUNTER WEIGHTS COUNTERWEIGHT & FTGS
View Diagram -
DIAG-B170-5-1-404775 B170-5-1 BONNET/ ENGINE COVERS/ GRILLES COVER PLATE FRONT ASSEMBLY
View Diagram
