Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | BONNET ABI 128/G2288 | 1 | $4,296.21 | |||
| 2 | LATCH STRIKER WA L 128/G3454 | 1 | $15.95 | |||
| 4 | SCREW, M8 x 16 - BUTTON HEAD(KANBAN) 826/11284 | 1 | $1.55 | |||
| 7 | SET-SCREW M_8 L-20mm 1315/0305Z | 1 | $1.25 | |||
| 8 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 9 | NUT M_6 STD PLAIN 1370/0101Z 1370/0101D | 1 | $2.14 | |||
| 10 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
Showing 1 to 7 of 7 parts
Related Assemblies
-
DIAG-B170-50-1-394802 B170-50-1 BONNET/ ENGINE COVERS/ GRILLES COVER PLATE DETAILS TOWER, 2WS/AWS, STAGE V
View Diagram -
DIAG-B170-40-1-394802 B170-40-1 BONNET/ ENGINE COVERS/ GRILLES FRAME ASSEMBLY
View Diagram -
DIAG-B170-55-1-394802 B170-55-1 BONNET/ ENGINE COVERS/ GRILLES ASSEMBLY
View Diagram
