Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA UPPER SUPPORT 333/U3472 | 1 | $565.27 | |||
| 2 | PANNIER SUPPORT FRONT 334/L9395 | 1 | $174.75 | |||
| 3 | WA PANNIER SUPPORT REAR 334/L9401 | 1 | $851.40 | |||
| 4 | WA PANNIER SUPPORT FRONT 333/V1393 | 1 | $332.10 | |||
| 5 | STEP FRAME WA 334/L9399 | 1 | $1,230.75 | |||
| 6 | STEP TREAD 410x180 331/27034 | 1 | $170.48 | |||
| 9 | MAT UREA TANK 333/U8527 | 1 | $45.40 | |||
| 10 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 11 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 12 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 13 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 15 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 16 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 17 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 18 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 19 | Nut M12 STD SELF LOCK 1370/0403D | 1 | $1.01 | |||
| 20 | WASHER M12 PLAIN 1420/0009D | 1 | $1.07 | |||
| 21 | SET-SCREW M12 L-_35mm 1315/0509D | 1 | $1.67 | |||
| 23 | SUPPORT WA 333/U3507 | 1 | $334.84 | |||
| 25 | (P) RIVET NUT M8 CSK 826/01261 | 1 | $19.40 | |||
| 26 | MAT FUEL TANK UPPER 333/U8525 | 1 | $16.80 | |||
| 27 | SET SCREW M10x35 1315/0409D | 1 | $10.55 | |||
| 28 | SET-SCREW M10 L-_40mm 1315/0410D | 1 | $2.49 | |||
| 29 | BLOCK SUPPORT 333/V1261 | 1 | $47.90 | |||
| 30 | HEX SCREW M6x32 LG 1315/0208D | 1 | $0.51 | |||
| 31 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 32 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
Showing 1 to 27 of 27 parts
Related Assemblies
-
DIAG-B120-3-1-393603 B120-3-1 FUEL TANK
View Diagram -
DIAG-B120-5-5-393603 B120-5-5 FUEL TANK ASSEMBLY
View Diagram -
DIAG-B120-2-1-393603 B120-2-1 FUEL TANK ASSEMBLY
View Diagram
