Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | FENDER MOULDING - LH REAR 331/23061 | 1 | $343.47 | |||
| 2 | FENDER MOULDING RH REAR 331/23062 | 1 | $352.23 | |||
| 3 | SPAT BRACKET LOWER RH 331/68869 | 1 | $66.45 | |||
| 4 | SPAT BRACKET LOWER LH 331/68870 | 1 | $151.10 | |||
| 5 | SET SCREW M16x50 1315/0712Z | 1 | $12.55 | |||
| 6 | SPAT BRACKET TOP RH 331/68867 | 1 | $62.21 | |||
| 7 | SPAT BRACKET TOP LH 331/68868 | 1 | $46.26 | |||
| 8 | SET-SCREW M_8 L-25mm 1315/0307 1315/0307Z | 1 | $3.11 | |||
| 9 | BOLT M8x30 1315/3308Z | 1 | $0.50 | |||
| 10 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 11 | WASHER 5/16 LARGE PLAIN 1412/0002Z 1412/0002D | 1 | $1.92 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 13 | SET-SCREW M10 L-_50mm 1315/0412Z | 1 | $3.61 | |||
| 14 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 15 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-B1-7-1-393558 B1-7-1 QUIET BUILD KIT
View Diagram -
DIAG-B1-6-2-393558 B1-6-2 FENDERS REAR
View Diagram -
DIAG-B1-8-1-393558 B1-8-1 LIGHT MOUNTING BARS
View Diagram
