Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 2 | Bolt M24 x 340 lon 1315/4037D | 1 | $127.14 | |||
| 3 | NUT M24 1370/0903D | 1 | $15.30 | |||
| 4 | WASHER M24 1420/0014D | 1 | $4.62 | |||
| 5 | HEX.BOLT M16x110 LG 1315/3721D | 1 | $24.54 | |||
| 6 | M16 LOCK NUT 1370/0603D | 1 | $21.78 | |||
| 7 | WASHER M16 PLAIN 1420/0011D | 1 | $1.43 | |||
| 8 | TOWING PIN.ZINC PLTD. 295/00287 | 1 | $55.51 | |||
| 9 | R CLIP 821/00514 | 1 | $7.49 | |||
| 11 | WASHER WEDGE 295/00391 | 1 | $211.92 | |||
| 12 | LABEL JCB 817/04837 | 1 | $135.54 | |||
| 13 | BRACKET MOUNTING 295/10070 | 1 | $173.78 | |||
| 14 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 15 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 16 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 17 | COUNTERWEIGHT HOLE COVER 826/11703 | 1 | $1.76 | |||
| 18 | SHIM 2.00MM 191/50003 | 1 | $66.23 | |||
| 19 | SHIM-1.2MM 191/50002 | 1 | $51.12 | |||
| 20 | Panel 331/26231 | 1 | $55.14 | |||
| 21 | Panel 331/26232 | 1 | $54.33 | |||
| 23 | SET-SCREW M16 L-_40mm 1315/0710D | 1 | $3.11 | |||
| 24 | THIN NUT M16 1370/0602D | 1 | $1.46 | |||
| 25 | PLATE-SPACER 331/52307 | 1 | $31.14 | |||
| 26 | SPACER-WEDGE 829/31321 | 1 | $16.86 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-B1-4-2-397201 B1-4-2 COVER, ENGINE SIDE
View Diagram -
DIAG-B1-3-2-397201 B1-3-2 BODYWORK
View Diagram -
DIAG-B1-1-2-397201 B1-1-2 CHASSIS AND FITTINGS
View Diagram
