Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| AUXILIARY PIPE MOUNT BRKT 331/31390 | 1 | $103.33 | ||||
| CAPSCREW M12X35 1391/3509 | 1 | $4.41 | ||||
| M8 Hardened Washer JHP0080 | 1 | $2.28 | ||||
| Pin GA Slew Lock 239/00059 | 1 | $208.81 | ||||
| SET-SCREW M_8 L-25mm 1315/0307 1315/0307Z | 1 | $3.11 | ||||
| 1 | SLEWFRAME M/C 458/20519 | 1 | $7,052.92 | |||
| 6 | REACTION PLATE 331/30592 | 1 | $170.20 | |||
| 6A | TORQUE ARM 331/30591 | 1 | $178.58 | |||
| 7 | Pin pivot 811/90343 | 1 | $284.36 | |||
| 9 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
| 10 | DOWEL 2105/1609 | 1 | $7.88 | |||
| 11 | BOLT M12 x 1.25 x 40 LG 826/10957 | 1 | $3.40 | |||
| 11 | SCREW HEX. HEAD 826/01550 | 1 | $7.21 | |||
| 12 | (W) (P)WASHER 13x23x2.7 823/00309 | 1 | $17.88 | |||
| 13 | SCREW M10x25 COUNTERSUNK 826/01512 | 1 | $8.60 | |||
| 13A | SET-SCREW M10 L-_25mm 1315/0407 1315/0407Z | 1 | $5.34 | |||
| 14 | WASHER M10 1422/0008D JHP0046 | 1 | $11.36 | |||
| 15 | BRONZE BEARING 831/10217 | 1 | $120.30 | |||
| 19 | Plate pin lock 331/31033 | 1 | $56.28 | |||
Showing 1 to 19 of 19 parts
