Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA POD BASE - UNPAINTED 333/D1138 | 1 | $2,204.09 | |||
| 2 | BOTTOM BLANKING PLATE 333/C2490 | 1 | $501.09 | |||
| 3 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 4 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 5 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 6 | FRONT ACCESS PLATE 335/09882 332/F5118 | 1 | $196.59 | |||
| 7 | Screw flange head 826/11013 | 1 | $2.47 | |||
| 8 | WA LATCH BRACKET 332/F5175 | 1 | $166.33 | |||
| 9 | Seal Edge 3600mm C 401/Y2815 926/06801 | 1 | $284.40 | |||
Showing 1 to 9 of 9 parts
Related Assemblies
-
DIAG-B1-5-7-400911 B1-5-7 POD BASE ASSEMBLY
View Diagram -
DIAG-B1-5-4-400911 B1-5-4 ENGINE POD BASE AIRFLOW TRACTOR BUILD
View Diagram -
DIAG-B1-5-2-400911-13050585 B1-5-2 ENGINE POD,BASE WITH ACCESS PANEL
View Diagram
