Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA REARLIGHT ARM 335/03051 | 1 | $331.70 | |||
| 4 | NUT M12 STD SELF LOCK 1370/0403Z | 1 | $6.91 | |||
| 5 | WASHER 123/02453 | 1 | $18.17 | |||
| 6 | RUBBER LIGHT ARM 331/27302 | 1 | $17.60 | |||
| 7 | BOLT M12X130 1315/3523Z | 1 | $16.86 | |||
| 8 | WASHER M12 PLAIN(KANBAN) 1420/0009Z | 1 | $1.15 | |||
| 9 | GROMMET 828/00389 | 1 | $22.52 | |||
| 10 | PLATE REAR LIGHT 331/25422 | 1 | $62.64 | |||
| 11 | WASHER 1/2 LARGE PLAIN 1412/0005Z | 1 | $2.73 | |||
| 12 | SET SCREW M6 X 16 GRADE 8.8 1315/0203Z 1315/0203D | 1 | $0.54 | |||
| 13 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 14 | WA HARNESS TIE PLATE SILVER 264/36400 | 1 | $26.07 | |||
| 15 | CABLE TIE 120mm 204/07006 | 1 | $1.64 | |||
Showing 1 to 13 of 13 parts
Related Assemblies
-
DIAG-B1-4-6-400683 B1-4-6 MIRROR/LIGHT MOUNTING,RH
View Diagram -
DIAG-B1-4-16-400683 B1-4-16 MIRROR ASSEMBLY BONNET,QUICKHITCH
View Diagram -
DIAG-B1-4-5-400683 B1-4-5 MIRROR/LIGHT MOUNTING,LH
View Diagram
