Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 2 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 3 | SET SCREW M8 x 45 G8.8 (P564) 1315/0311D | 1 | $9.72 | |||
| 4 | BOLT M8x60 (P564) 1315/3314D | 1 | $33.85 | |||
| 7 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
| 9 | THIN NUT M10 1370/0302D | 1 | $2.00 | |||
| 10 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 11 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 12 | BONNET HANDLE 332/R1479 | 1 | $144.64 | |||
| 13 | WA - SEAT MOUNTING FRAME 332/T4283 | 1 | $1,035.11 | |||
| 14 | HINGE BLOCK - SEAT BASE 332/R7307 | 1 | $236.84 | |||
| 15 | HINGE BLOCK - CHASSIS 332/R7309 | 1 | $58.65 | |||
| 17 | FRONT BONNET ABI 332/T3213 | 1 | $2,843.63 | |||
| 18 | HOOK PLATE 332/S1485 | 1 | $17.33 | |||
| 19 | BONNET LATCH PIVOT 332/S2282 | 1 | $11.22 | |||
| 20 | SPACER 332/S2528 | 1 | $2.83 | |||
| 21 | WA-BONNET LATCH ANGLE 332/S2545 | 1 | $82.78 | |||
| 23 | (P) LOCK BARREL ASSY 826/10101 | 1 | $98.18 | |||
| 24 | BEARING 831/00119 | 1 | $32.06 | |||
| 25 | SPRING PIN ESM6 913/00031 | 1 | $12.08 | |||
| 26 | CONTROL ROD ASSY - LIFT/L 913/10274 | 1 | $152.71 | |||
| 27 | EDGING STRIP.350mm lg. 926/04812 | 1 | $6.08 | |||
| 31 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 32 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 34 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 35 | GAS STRUT 332/V6489 | 1 | $82.95 | |||
| 41 | NUT M10 PLAIN 1370/0301Z 1370/0301D | 1 | $3.28 | |||
| 42 | WA BONNET LATCH 332/R6839 | 1 | $64.34 | |||
| 43 | BOLT M10x65 1315/3415D | 1 | $7.10 | |||
| 45 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 53 | (W) (P) SCREW CSK SKT HEAD 332/S2118 | 1 | $2.41 | |||
Showing 1 to 31 of 31 parts
Related Assemblies
-
DIAG-B1-3-1-404339 B1-3-1 CENTRE PIVOT
View Diagram -
DIAG-B1-4-10-404339 B1-4-10 ENGINE COVER REAR & MOULDINGS
View Diagram -
DIAG-B1-2-1-404339 B1-2-1 FLOOR PLATE & STEPS
View Diagram
