Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | Condenser epoxy co 30/926448 | 1 | $4,874.94 | |||
| 3 | WA STRIKER BRKT 332/W8833 | 1 | $42.83 | |||
| 5 | LATCH bonnet 331/27126 | 1 | $19.83 | |||
| 6 | LOCK STRIKER PIN 331/34215 | 1 | $5.34 | |||
| 8 | (P) BEARING - 10 ID PLASTIC 332/T2015 | 1 | $3.21 | |||
| 9 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 10 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 11 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 12 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 13 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 14 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
| 15 | SET-SCREW M_6 L-_20mm 1315/0205D | 1 | $0.57 | |||
| 16 | SET SCREW M6 x 40 G8.8 1315/0210D | 1 | $0.81 | |||
| 17 | SCREW M8x30 COUNTERSUNK 826/10811 | 1 | $1.55 | |||
| 18 | SPACER 332/Y7440 | 1 | $25.74 | |||
Showing 1 to 15 of 15 parts
