Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | COUNTERWEIGHT - 411 331/56930 | 1 | $12,345.06 | |||
| 2 | Bolt M24 x 340 lon 1315/4037D | 1 | $127.14 | |||
| 3 | BOLT 1315/4021D | 1 | $27.63 | |||
| 4 | WASHER-M24, 8 THK 823/10643 | 1 | $140.35 | |||
| 5 | WASHER M24 1420/0014D | 1 | $4.62 | |||
| 6 | NUT M24 1370/0903D | 1 | $15.30 | |||
| 11 | TOW PIN 268/00172 | 1 | $430.52 | |||
| 12 | RETAINING ROPE 476/26707 | 1 | $17.91 | |||
| 14 | LYNCH PIN 826/00512 | 1 | $3.76 | |||
| 15 | RECOVERY BRACKET 331/50791 | 1 | $866.77 | |||
| 16 | HEX.BOLT M24x140 LG 1315/4024D | 1 | $44.50 | |||
| 17 | NUT M24 STD PLAIN 1370/0901D | 1 | $6.62 | |||
| 18 | HARDENED WASHER M24 1422/0014D | 1 | $8.12 | |||
| 19 | BLANKING PLUG 333/T9529 | 1 | $0.62 | |||
| 19 | Plug Yellow M30 835/00170 | 1 | $14.41 | |||
Showing 1 to 15 of 15 parts
