Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA STEP FRAME 332/W6389 | 1 | $465.01 | |||
| 2 | STEP TREAD 410x180 331/27034 | 1 | $170.48 | |||
| 3 | WA RH LOWER STEP MTG 332/U4890 | 1 | $92.73 | |||
| 4 | WA LH LOWER STEP MTG 332/U4888 | 1 | $92.73 | |||
| 5 | 3LEXI STEP MOUNTING 332/V0846 | 1 | $104.69 | |||
| 6 | WASHER 3/8IN LARGE 1412/0003D | 1 | $0.57 | |||
| 7 | SET-SCREW M10 L-_40mm 1315/0410D | 1 | $2.49 | |||
| 8 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 9 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 10 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 11 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 12 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 13 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
Showing 1 to 13 of 13 parts
