Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| CABLE TIE - BLACK 300mm 121/77603 | 1 | $0.95 | ||||
| 3 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 4 | ADAPTOR:BATTERYPLATE 816/60068 | 1 | $78.83 | |||
| 5 | TUBE BUNDY 232/49103 | 1 | $35.50 | |||
| 6 | ADAPTER 231/19000 231/19001 | 1 | $3.88 | |||
| 7 | OLIVE 231/19002 | 1 | $3.79 | |||
| 9 | (P) BOLT M12x60 1316/3514Z | 1 | $17.79 | |||
| 9 | BOLT M12x70 1316/3516Z | 1 | $4.90 | |||
| 9 | BOLT M14 X 60 1316/3614Z | 1 | $3.88 | |||
| 9 | BOLT M14 X 70 1316/3616Z | 1 | $3.12 | |||
| 10 | SPECIAL WASHER 823/00540 | 1 | $10.23 | |||
| 10 | SPECIAL WASHER M12 823/00394 | 1 | $2.96 | |||
| 11 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 12 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 15 | BOLT M8x120 1315/3322Z | 1 | $4.11 | |||
| 16 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 20 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 21 | SELF LOCK STD. 1370/0303 | 1 | $2.26 | |||
| 23 | RIVET 826/01774 | 1 | $0.30 | |||
| 25 | GUARD SUMP 232/20309 | 1 | $1,036.57 | |||
Showing 1 to 20 of 20 parts
Related Assemblies
-
DIAG-B1-1-3-397923 B1-1-3 MAINFRAME
View Diagram -
DIAG-B1-2-1-397923 B1-2-1 TANK, DIESEL FUEL
View Diagram -
DIAG-B1-1-1-397923-12044717 B1-1-1 MAINFRAME AND COUNTERWEIGHTS
View Diagram
