Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| CABLE TIE - BLACK 300mm 121/77603 | 1 | $0.95 | ||||
| SHIM 1.0mm 823/00237 | 1 | $12.32 | ||||
| SHIM 51x76x1.4mm 823/00220 | 1 | $14.79 | ||||
| 5 | BOLT 1315/4034 | 1 | $110.93 | |||
| 5 | BOLT M24x280 1315/4034Z | 1 | $94.46 | |||
| 6 | Bolt 1315/4033Z | 1 | $63.91 | |||
| 6 | Bolt plain 1315/4033 | 1 | $48.51 | |||
| 7 | Nut 1370/0903 | 1 | $27.73 | |||
| 7 | NUT DRY LUBE 826/10372 | 1 | $58.65 | |||
| 8 | WASHER M24 DRY LUB 823/10230 | 1 | $17.82 | |||
| 10 | PIN PIVOT 811/10072 | 1 | $659.33 | |||
| 11 | BOLT M10x100 1315/3420Z | 1 | $8.86 | |||
| 12 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 14 | WASHER 5/16 LARGE PLAIN 1412/0002Z 1412/0002D | 1 | $1.92 | |||
| 15 | SET SCREW M8x30(KANBAN) 1315/0308Z | 1 | $2.17 | |||
| 16 | SPACER AXLE 142/00718 | 1 | $32.53 | |||
| 17 | FLEXI GROMMET MTR 926/00600 | 1 | $3.82 | |||
| 22 | NUT RIVET M8 - ATB 826/01646 | 1 | $25.29 | |||
| 23 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
Showing 1 to 19 of 19 parts
Related Assemblies
-
DIAG-B1-1-2-395082-11170209 B1-1-2 CHASSIS EXCAVATOR
View Diagram -
DIAG-B1-2-1-395082 B1-2-1 FRAME, REAR
View Diagram -
DIAG-B1-2-5-395082 B1-2-5 STREET PADS FRAME,REAR CAST STABILISER FOOT
View Diagram
