Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | TIE MOUNT.CRADLE MNT. 826/01274 | 1 | $0.92 | |||
| 20 | CABLE TIE LOCKING(KANBAN) 826/11436 | 1 | $2.75 | |||
| 30 | DEUTSCH DT MNTG CLIP 7210/0067 | 1 | $26.59 | |||
| 40 | DEUTSCH MOUNTING CLIP M10 7210/0089 | 1 | $14.07 | |||
| 50 | NUT VIBRATION PROOF 826/01277 | 1 | $3.89 | |||
| 60 | CAP SCREW M4x20 1391/9405D | 1 | $2.51 | |||
| 70 | WASHER M4 PLAIN 1420/0004Z | 1 | $0.68 | |||
| 80 | NUT M4 STD SELF LOCK 1370/9403Z | 1 | $2.91 | |||
| 90 | HARNESS - SLEW MAN BASKET 721/E6898 | 1 | $277.92 | |||
| 100 | GROMMET STD 44.4x2 2410/0015 | 1 | $6.97 | |||
| 110 | SWITCH MACHINE ISOLATION (LK1) 701/80644 | 1 | $577.38 | |||
| 120 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 130 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 140 | COVER-HDC34 MALE 333/F6079 | 1 | $221.35 | |||
| 150 | WA HARNESS TIE PLATE SILVER 264/36400 | 1 | $26.07 | |||
| 160 | BOLT M10x40 1315/3410Z | 1 | $5.45 | |||
| 170 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 180 | PIN RETENTION PLATE 331/40926 | 1 | $66.49 | |||
| 190 | (W) (P) KEYRING 152/17502 332/F5173 | 1 | $3.17 | |||
| 200 | LYNCH PIN 4.5MM DIA 332/U0263 | 1 | $3.23 | |||
| 210 | BRACKET - CABLE REEL SLEW 333/D2770 | 1 | $366.86 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-A760-55-1-401904 A760-55-1 MAN PLATFORM INSTALLATION RIBBED SQUARE INSERT 5m FIXED
View Diagram -
DIAG-A760-25-1-401904 A760-25-1 MAN PLATFORM SLEW LOCK
View Diagram -
DIAG-A760-20-5-401904 A760-20-5 MAN PLATFORM SLEW 2.5-5M L
View Diagram
