Kubota BX1870 A53501 BATTERY Parts Diagram
Exploded-view parts diagram "A53501 BATTERY" for the Kubota BX1870 and Kubota BX1870-1. 9 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 012 | LABEL, BATTERY K1221-61180 Discontinued | 1 | $6.98 | |||
| 020 | HOOK, BATTERY K2581-61120 | 1 | $22.29 | |||
| 030 | CABLE, BATTERY + K2581-61310 K2581-61312 | 1 | $34.52 | |||
| 035 | Nut Fastener W2336-07200 02114-50080 | 1 | $0.60 | |||
| 037 | Spring Washer 04512-50080 | 1 | $0.87 | |||
| 040 | CABLE, BATTERY ( K2581-61352 K2581-61353 | 1 | $22.00 | |||
| 050 | CABLE, BATTERY2( K1211-61360 | 1 | $6.28 | |||
| 060 | Flange Bolt - M8 x 1.25 x 20 mm 01754-50820 | 1 | $4.70 | |||
| 070 | Flange Nut TA140-18310 02751-50080 | 1 | $4.62 | |||
Showing 1 to 9 of 9 parts
