Kubota RTV900G A42000 RADIATOR Parts Diagram
Exploded-view parts diagram "A42000 RADIATOR" for the Kubota RTV900G, Kubota RTV900G6, Kubota RTV900R-SD/R-SDL, Kubota RTV900R6, Kubota RTV900T, Kubota RTV900T5-H/T2, Kubota RTV900T6 and Kubota RTV900W and 1 more models. 13 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY, RADIATOR K7561-85210 | 1 | $804.47 | |||
| 020 | Radiator Cap TA140-16060 17580-16060 | 1 | $48.92 | |||
| 030 | PLUG, DRAIN 34070-16070 | 1 | $19.55 | |||
| 040 | O RING 34070-16090 | 1 | $10.74 | |||
| 050 | Radiator Rubber 34070-16030 | 1 | $3.75 | |||
| 060 | HOLDER 1, RADIAT K7561-85430 K7561-85432 | 1 | $117.63 | |||
| 070 | HOLDER 2, RADIAT K7561-85440 K7561-85442 | 1 | $125.13 | |||
| 080 | Flange Bolt - M8 x 1.25 x 16 mm 01754-50816 | 1 | $4.33 | |||
| 090 | KIT COVER, RADIA K7567-98200 | 1 | $97.02 | |||
| 090 | KIT, COVER (FAN) K7561-98200 | 1 | $57.02 | |||
| 110 | NET, RADIATOR K7561-85412 K7561-85413 | 1 | $73.00 | |||
| 120 | SUPPORT, NET K7561-85470 K7561-85473 | 1 | $40.28 | |||
| 130 | CLIP,NET SUPPORT K7561-85480 K7561-85482 | 1 | $0.71 | |||
Showing 1 to 13 of 13 parts
