A370-90-1 FORKS INSTALLATION KIT Parts Diagram | JCB | Scholten’s Equipment

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
2	Washer 333/C0529	1	AVAILABLE TO ORDER	$5.27	Quantity
3	Capscrew 333/C5764	1	AVAILABLE TO ORDER	$6.42	Quantity
6	Capscrew 333/C0516	1	AVAILABLE TO ORDER	$5.24	Quantity
7	Fitting 336/C6749	1	AVAILABLE TO ORDER	$109.73	Quantity
8	Hose 400/04080	1	AVAILABLE TO ORDER	$267.46	Quantity

Showing 1 to 5 of 5 parts

DIAG-A370-85-1-397319 A370-85-1 FORKS POSITIONER ASSEMBLY
View Diagram
DIAG-A370-80-1-397319 A370-80-1 FORKS FORK CASCADE 65K SS
View Diagram
DIAG-A370-70-1-397319 A370-70-1 FORKS BASE UNIT GROUP
View Diagram

Previous Assembly DIAG-A370-85-1-397319 A370-85-1 FORKS POSITIONER ASSEMBLY Next Assembly DIAG-B110-15-1-397319 B110-15-1 CHASSIS 35D 4WD T4 ABI
