Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| Data plate 401/Y8099 400/00258 | 1 | $278.19 | ||||
| 10 | Q-FIT CARRIAGE RAL7039 400/C7220 | 1 | $1,871.60 | |||
| 20 | 402/H8495 400/K6619 | 1 | $65.03 | |||
| 30 | P-PIN 19.05/18.95x114 811/50169 400/K8432 | 1 | $31.17 | |||
| 40 | MANUAL LEVER W.A. MAN P 400/K5829 | 1 | $442.96 | |||
| 50 | WA LONG LINK 400/K6008 | 1 | $306.28 | |||
| 60 | WA LOCKING PIN 400/K6252 | 1 | $63.41 | |||
| 70 | P/PIN 20.00/19.92 * 80 348/00024 811/90265 | 1 | $23.61 | |||
| 80 | LINK PLATE 333/D9647 | 1 | $90.88 | |||
| 90 | SET SCREW M10x35 1315/0409D | 1 | $0.00 | |||
| 100 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.00 | |||
| 110 | (W) (P) SET SCREW M6x40 1315/0210Z | 1 | $6.06 | |||
| 120 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $0.80 | |||
| 130 | PIVOT PIN 49.90 x 183 334/C0658 | 1 | $531.02 | |||
| 140 | PIVOT PIN 50 DIA 332/E4255 | 1 | $220.98 | |||
| 150 | BOLT M12x110 1315/3521D | 1 | $4.63 | |||
| 160 | BOLT M12x100 1315/3520D | 1 | $2.94 | |||
| 170 | NUT M12 SELF LOCK 1371/0403D | 1 | $6.69 | |||
| 180 | Q-FIT DECAL 403/F8342 | 1 | $1.05 | |||
| 200 | NIPPLE GREASE 816/60056 816/60056A | 1 | $0.23 | |||
| 210 | SPRING 814/00106 400/K6240 | 1 | $15.51 | |||
| 230 | LYNCH PIN & CHAIN 826/00819 | 1 | $27.62 | |||
| 240 | KEY RING 152/17501 | 1 | $0.00 | |||
| 260 | HITCH PIN (3/4") 400/K7910 | 1 | $19.49 | |||
| 270 | SCREW 4X1/4 826/00115 | 1 | $1.43 | |||
| 280 | WASHER M12 PLAIN 1420/0009D | 1 | $0.00 | |||
| 290 | BUSHING 831/00035 | 1 | $49.72 | |||
| 300 | LYNCH PIN 826/01278 | 1 | $0.00 | |||
| 330 | WASHER LOCK M10 823/10261 | 1 | $5.93 | |||
| 340 | SPACER - 10.1 x 13.9 x 11 334/E5752 | 1 | $42.46 | |||
Showing 1 to 30 of 30 parts
Related Assemblies
-
DIAG-A370-115-1-400649 A370-115-1 FORKS INSTALLATION FORK POSITIONER , 50 MM
View Diagram -
DIAG-A370-120-1-400649 A370-120-1 FORKS ASSEMBLY POSITIONER , 4T (Q-FIT)
View Diagram -
DIAG-A370-125-1-400649 A370-125-1 FORKS POSITIONER , 4T (Q-FIT)
View Diagram
