Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| KIT-AIR CON 980/90285 | 1 | $3,432.31 | ||||
| 1 | ABI - AIRCON 332/D0577 160/13917 | 1 | $2,579.62 | |||
| 2 | BELT, DRIVE L=2002 320/08608 | 1 | $50.13 | |||
| 3 | IDLER PULLEY - A/C (new 08921) 320/08530 320/08773 | 1 | $69.42 | |||
| 4 | COMPRESSOR 12v 8203 320/08562 | 1 | $1,236.68 | |||
| 5 | BOLT 6 LOBED M8x100(KANBAN) 1319/3320Z | 1 | $11.51 | |||
| 6 | HOSE AIR CONDITIONING 649/52167 | 1 | $356.40 | |||
| 7 | HOSE AIR CONDITIONING 649/51929 | 1 | $219.08 | |||
| 8 | HOSE AIR CONDITIONING 649/51880 | 1 | $153.03 | |||
| 9 | HOSE AIR CONDITIONING 649/51881 | 1 | $91.90 | |||
| 10 | HOSE AIR CONDITIONING 649/51882 | 1 | $93.43 | |||
| 11 | HOSE AIR CONDITIONING 649/51883 | 1 | $132.13 | |||
| 12 | (W) (P) BINARY SWITCH 335/E4691 701/58726 | 1 | $172.21 | |||
| 13 | CONDENSER aircon 30/925766 | 1 | $720.59 | |||
| 14 | WA RH CONDR S/FRM 335/04985 | 1 | $149.39 | |||
| 15 | WA LH CONDENSER S/FRM 335/04992 | 1 | $149.39 | |||
| 16 | WA BRACKET CONDENSER RH 335/09790 | 1 | $171.03 | |||
| 17 | WA BRACKET CONDENSER LH 335/09791 | 1 | $155.42 | |||
| 18 | LINK PRESSING 331/33282 | 1 | $20.50 | |||
| 19 | 1_4 TURN FASTENER 826/10532 | 1 | $65.46 | |||
| 20 | PIVOT SPACER 829/30874 | 1 | $1.64 | |||
| 21 | RETAINER 478/00288 | 1 | $26.12 | |||
| 22 | NYLON WASHER M8 123/04791 | 1 | $2.82 | |||
| 23 | SET-SCREW M_6 L-_25mm 1315/0207Z 1315/0207D | 1 | $0.33 | |||
| 24 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 25 | BOLT M6x40 1315/3210Z | 1 | $0.81 | |||
| 26 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 27 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 28 | (W) P-CLIP - 25mm(KANBAN) 821/00329 | 1 | $6.83 | |||
| 29 | (W) (Pre-P)-SET SCREW M6x45 1315/0211Z | 1 | $2.47 | |||
| 30 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 31 | BRACKET A/C HOSE 331/52174 | 1 | $252.32 | |||
| 32 | RECEIVER / DRIER 30/925633 | 1 | $205.83 | |||
| 33 | BRACKET RECEIVER DRIER 331/52164 | 1 | $72.76 | |||
| 34 | CLIP - WORMDRIVE 70/90mm(KANBAN) 2201/0014 | 1 | $7.20 | |||
| 35 | SET-SCREW M10 L-_25mm 1315/0407 1315/0407Z | 1 | $5.34 | |||
| 36 | CABLE TIE-225MM 826/01092 | 1 | $4.11 | |||
| 37 | FIT INST ISS 02 9814/0529 | 1 | $262.07 | |||
Showing 1 to 38 of 38 parts
