| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| BOLT M10x80(KANBAN) 1315/3418Z | 1 | $1.63 | ||||
| 1 | VALVE 25/973300 | 1 | $631.05 | |||
| 4 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 5 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 6 | ADAPTOR G3/4A M/M 1604/0006 | 1 | $12.35 | |||
| 8 | WASHER BONDED 1" BSP 1406/0021 | 1 | $6.00 | |||
| 9 | HOSE 1/2BSP 340mm 613/47400 | 1 | $141.76 | |||
| 10 | ADAPTOR 1604/0004 1604/0004A | 1 | $3.63 | |||
| 11 | WASHER 1406/0018 | 1 | $4.09 | |||
| 13 | KIT-SEAL 20/301001 | 1 | $165.01 | |||
| 14 | ADAPTOR -TEE 816/50014 | 1 | $57.36 | |||
| 15 | HOSE 1/4BSP 440mm 611/26300 | 1 | $91.25 | |||
| 16 | ADAPTOR G1/4A M/M 1604/0002 | 1 | $29.81 | |||
| 17 | WASHER BONDED 1/4 BSP 1406/0011 | 1 | $1.52 | |||
| 18 | HOSE 1/2BSP 205mm 613/06900 | 1 | $30.75 | |||
| 19 | PIPE ASSY 980/32900 | 1 | $217.45 | |||
| 20 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 21 | WASHER 1/4 MEDIUM PLAIN 1411/0001Z | 1 | $0.14 | |||
| 22 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 23 | PC ADAPTOR 816/00335 | 1 | $28.85 | |||
| 24 | PIPE ASSY 980/33000 | 1 | $130.57 | |||
| 25 | HOSE 3/4BSP 1980mm 615/00800 | 1 | $416.25 | |||
| 26 | ADAPTOR G3/4A-G1/2A 1606/0009 | 1 | $28.09 | |||
| 28 | COUPLING QR MALE F9 - 1/2BSP 45/910500 | 1 | $78.76 | |||
Showing 1 to 24 of 24 parts
