Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| Data plate 401/Y8099 400/00258 | 1 | $278.19 | ||||
| 3 | KV 980mm straight tine 980/72703 334/E4564 | 1 | $386.62 | |||
| 4 | GRAB TINE 980/72704 | 1 | $374.50 | |||
| 5 | RAM ASSY 980/72910 | 1 | $3,334.79 | |||
| 6 | PIN PIVOT 980/72705 | 1 | $378.27 | |||
| 8 | PIN 980/72707 | 1 | $364.70 | |||
| 9 | PIN 980/72708 | 1 | $367.77 | |||
| 10 | BOLT HEX BOLT & NU 980/72709 | 1 | $160.54 | |||
| 11 | BOLT HEX BOLT & NU 980/72710 | 1 | $92.21 | |||
| 12 | HOSE - STRIMECH MANURE FORK 545/43709 | 1 | $235.66 | |||
| 13 | ADAPTOR 545/43710 | 1 | $148.08 | |||
| 14 | HOSE 612/06700 | 1 | $360.94 | |||
| 15 | ADAPTOR G3/8A M/M 1604/2052 | 1 | $18.27 | |||
| 16 | WASHER BONDED 3/8" BSP(KANBAN) 1406/0015 | 1 | $1.52 | |||
| 17 | COUPLING QR MALE 3/8BSP 45/910700 | 1 | $60.31 | |||
| 18 | COUPLING QR FEMALE 3/8BSP 45/910600 | 1 | $120.27 | |||
Showing 1 to 16 of 16 parts
Related Assemblies
-
DIAG-A3-12-1-400160 A3-12-1 FORK, MANURE, SILAGE WITH TOP GRAB 2.29M WIDE X 1.9CU.M
View Diagram -
DIAG-A3-13-1-400160 A3-13-1 FORK, MANURE, SILAGE WITH TOP GRAB & PUSH OFF UNIT, 7'6 "WIDE X 65CU.FT
View Diagram -
DIAG-A3-11-1-400160 A3-11-1 FORK, MANURE, SILAGE 2.29M WIDE X 1.9CU.M
View Diagram
