Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | TUBE,FUEL,ASSY(1) 3C131-04462 3C131-04463 | 1 | $49.40 | |||
| 020 | TUBE,FUEL 09661-71600 | 1 | $41.91 | |||
| 030 | BAND, HOSE * 09318-88115 | 1 | $3.16 | |||
| 040 | Retaining Clip 09318-88125 | 1 | $2.26 | |||
| 050 | ASSY TUBE, FUEL 3C001-04490 | 1 | $40.44 | |||
| 060 | TUBE, FUEL 09661-80060 | 1 | $3.38 | |||
| 070 | Pipe Clip for Fuel Pipe and Fuel Filter Lines 16241-42750 14911-42750 | 1 | $4.60 | |||
| 080 | ASSY TUBE, FUEL 3C001-04500 | 1 | $29.99 | |||
| 090 | TUBE, FUEL 3C001-04510 | 1 | $10.25 | |||
| 110 | JOINT RB411-51320 | 1 | $35.63 | |||
| 120 | TUBE,FUEL,ASSY(2) 3C131-04020 3C131-04022 | 1 | $21.47 | |||
| 130 | TUBE, FUEL 09661-70440 | 1 | $9.57 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-A14100-96499 A14100 FUEL PIPE (FILTER/SUPPLY PUMP)
View Diagram -
DIAG-A14400-96499 A14400 FUEL PIPE (FUEL COOLER)
View Diagram -
DIAG-A13500-96499 A13500 FUEL FILLER
View Diagram
