Kubota M6040DT-1 A14001 FUEL PIPE [OLD] Parts Diagram
Exploded-view parts diagram "A14001 FUEL PIPE [OLD]" for the Kubota M6040DT-1, Kubota M6040F-1 and Kubota M6040HD-1. 12 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY TUBE, FUEL 3C081-04460 | 1 | $51.65 | |||
| 020 | TUBE FUEL 09661-81850 | 1 | $28.79 | |||
| 030 | Pipe Clip for Fuel Pipe and Fuel Filter Lines 16241-42750 14911-42750 | 1 | $4.60 | |||
| 040 | ASSY TUBE, FUEL 3C081-04470 | 1 | $25.11 | |||
| 050 | TUBE, FUEL 09661-41500 | 1 | $16.60 | |||
| 070 | ASSY TUBE, FUEL 3C001-04040 | 1 | $41.86 | |||
| 080 | TUBE, FUEL 09661-70180 | 1 | $4.84 | |||
| 100 | ASSY TUBE, FUEL 3C001-04490 | 1 | $40.44 | |||
| 110 | TUBE, FUEL 09661-80060 | 1 | $3.38 | |||
| 130 | ASSY TUBE, FUEL 3C001-04500 | 1 | $29.99 | |||
| 135 | TUBE, FUEL 3C001-04510 | 1 | $10.25 | |||
| 150 | JOINT RB411-51320 | 1 | $35.63 | |||
Showing 1 to 12 of 12 parts
