Kubota L4630DT/GST A11002 FUEL PIPE AND FUEL FILTER [CAB TYPE] Parts Diagram

Exploded-view parts diagram "A11002 FUEL PIPE AND FUEL FILTER [CAB TYPE]" for the Kubota L4630DT/GST. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
010 ASSY TUBE FUEL TD060-42610 1 1 IN STOCK $38.15
020 PIPE, FUEL K7711-34230 09664-80850 1 AVAILABLE TO ORDER $21.68
030 Retaining Clip 09318-88125 1 3 IN STOCK $2.26
040 ASSY TUBE, FUEL T1060-42620 1 2 IN STOCK $30.10
040 ASSY, TUBE FUEL TD060-42620 1 1 IN STOCK $30.10
050 PIPE, FUEL * 68131-52182 09664-80650 1 AVAILABLE TO ORDER $11.42
050 TUBE, FUEL 09664-80700 1 AVAILABLE TO ORDER $11.79
070 ASSY TUBE, FUEL T1060-42640 1 1 IN STOCK $20.16
080 TUBE, FUEL 09661-40750 1 AVAILABLE TO ORDER $12.16
090 Pipe Clip 14971-42751 14971-42750 1 6 IN STOCK $1.88
100 ASSY TUBE, FUEL TC020-42630 T0070-42642 1 AVAILABLE TO ORDER $11.36
110 TUBE, FUEL 09661-40600 1 3 IN STOCK $7.81
130 BRACKET,FILTER TD060-14410 TD140-16580 1 AVAILABLE TO ORDER $80.24
140 Flange Bolt 01754-50830 1 6 IN STOCK $5.85
150 CLAMP T1060-30150 1 AVAILABLE TO ORDER $3.16

Showing 1 to 15 of 15 parts
