Kubota L5240HSTC-3 A11000 FUEL PIPE Parts Diagram

Exploded-view parts diagram "A11000 FUEL PIPE" for the Kubota L5240HSTC-3 and Kubota L5740HSTC-3. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
010 ASSY TUBE FUEL TD060-42610 1 1 IN STOCK $38.15
020 PIPE, FUEL K7711-34230 09664-80850 1 AVAILABLE TO ORDER $21.68
030 Retaining Clip 09318-88125 1 3 IN STOCK $2.26
040 ASSY, TUBE FUEL TD060-42620 1 1 IN STOCK $30.10
050 TUBE, FUEL 09664-80700 1 AVAILABLE TO ORDER $11.79
070 ASSY TUBE, FUEL TD170-42630 1 AVAILABLE TO ORDER $22.96
080 TUBE, RUBBER 09661-40850 1 AVAILABLE TO ORDER $13.99
090 Pipe Clip 14971-42751 14971-42750 1 6 IN STOCK $1.88
100 ASSY TUBE, FUEL TD170-42640 1 AVAILABLE TO ORDER $17.20
110 TUBE, FUEL 09661-40700 1 AVAILABLE TO ORDER $12.16
140 Flange Bolt 01754-50830 1 6 IN STOCK $5.85
150 CLAMP T1060-30150 1 AVAILABLE TO ORDER $3.16
160 BAND, CORD 65601-42390 53581-64150 1 4 IN STOCK $4.85
170 BOLT, FLANGE * 01754-50608 1 AVAILABLE TO ORDER $1.21
180 CLAMP, CORD * 13824-67580 1 7 IN STOCK $1.83

Showing 1 to 15 of 15 parts
