A100-60-1 SHOVEL INSTALLATION ASSEMBLIES GRAIN SHOVEL, Q-FIT, 3.56CU.M. x 2450MM Parts Diagram | JCB

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
	GA GRAIN SHL 3.56m3 2450mm Q-FIT 980/A9981	1	AVAILABLE TO ORDER	$7,833.28	Quantity
	Set x 8 334/E8392	1	AVAILABLE TO ORDER	$122.33	Quantity
	Toeplate 2450mm (Bolt on) 334/E8561	1	AVAILABLE TO ORDER	$567.61	Quantity
	Wear Edge HB500 Boron 200 400/01233	1	AVAILABLE TO ORDER	$1,083.42	Quantity
2	AGRI LOGO - 500 X 86 335/H1331	1	AVAILABLE TO ORDER	$11.56	Quantity

Showing 1 to 5 of 5 parts
