Kubota L3770-CAB A05500 AUTO THROTTLE CAM Parts Diagram

Exploded-view parts diagram "A05500 AUTO THROTTLE CAM" for the Kubota L3770-CAB. 13 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.

Scroll to zoom Click a part # to view details

Ref # Part Number Qty. Avl. Price (USD) Action
010 BRACKET,AUTO THR TD350-54750 1 AVAILABLE TO ORDER $70.23
020 CAM,ASSY(HST,NEUTRAL TD350-55510 1 AVAILABLE TO ORDER $64.09
030 Lever Pivot Bushing 32530-36810 08511-01220 1 AVAILABLE TO ORDER $8.57
040 Plain Washer (Flat Washer) 04014-50120 04013-50120 1 9 IN STOCK $0.60
050 CIR-CLIP, INTERN 04612-10120 04612-00120 1 2 IN STOCK $0.60
060 PIN,AUTO THROTTL TD350-54730 1 AVAILABLE TO ORDER $31.11
070 ASSY ARM,NEUTRAL TD350-55100 1 AVAILABLE TO ORDER $73.49
080 BUSH 41081-12120 08511-01210 1 1 IN STOCK $5.05
090 BRG BALL RADIAL1 08121-06000 1 5 IN STOCK $10.17
100 Plain Washer 04011-00100 04011-50100 1 15 IN STOCK $0.36
110 CIR-CLIP 04612-50100 04612-00100 1 13 IN STOCK $0.60
120 PLATE, BODY RC441-66140 1 AVAILABLE TO ORDER $18.42
130 Flange Bolt - M8 x 1.25 x 16 mm 01754-50816 1 20 IN STOCK $4.33

Showing 1 to 13 of 13 parts
