Kubota SVL75C 583400 RADIATOR Parts Diagram
Exploded-view parts diagram "583400 RADIATOR" for the Kubota SVL75C. 26 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | COMP RADIATOR V0511-43504 V0521-43500 | 1 | $3,386.89 | |||
| 020 | CAP, RADIATOR V0511-43510 | 1 | $64.37 | |||
| 020 | CAP,RADIATOR V0511-43512 V0511-43513 | 1 | $64.37 | |||
| 025 | PLUG V0511-43930 | 1 | $79.75 | |||
| 027 | WASHER V0511-43940 | 1 | $15.20 | |||
| 030 | TRIM V0511-43920 | 1 | $17.99 | |||
| 050 | ELBOW 68881-64470 68881-64472 | 1 | $109.28 | |||
| 050 | JOINT,PIPE MR003-60610 | 1 | $61.53 | |||
| 060 | O-Ring Seal (Hydraulic/Oil Piping) 04817-00240 | 1 | $2.50 | |||
| 070 | JOINT RD809-61860 | 1 | $118.63 | |||
| 120 | RUBBER V0511-43522 | 1 | $6.13 | |||
| 130 | KIT SHROUD LABEL***FRENCH LABEL ONLY*** V0511-99302 V0511-99304 Discontinued | 1 | $286.88 | |||
| 130 | KIT.SHROUD,LABEL V0511-99300 | 1 | $151.56 | |||
| 130 | SHROUD,KIT(LABEL,A) .. V0511-99753 V0511-99756 | 1 | $273.95 | |||
| 150 | Bolt 01127-50825 | 1 | $1.57 | |||
| 160 | TRIM V0511-43590 | 1 | $36.31 | |||
| 170 | KIT STAY V0511-99763 V0511-99764 | 1 | $250.76 | |||
| 180 | Equipment Bolt for Seat, ROPS, and Battery Components 01135-51025 | 1 | $2.17 | |||
| 190 | STAY, RADIATOR V0511-43622 | 1 | $786.50 | |||
| 200 | GROMMET 52600-21180 | 1 | $5.04 | |||
| 210 | BUSHING, RADIATO V0511-43630 | 1 | $6.71 | |||
| 220 | BOLT V0511-43640 | 1 | $10.49 | |||
| 230 | ROLLER V0511-43650 | 1 | $8.71 | |||
| 240 | STAY, ROLLER V0511-43680 | 1 | $24.65 | |||
| 250 | Bolt - M10 x 1.25 x 20mm 01135-51020 | 1 | $1.99 | |||
| 260 | STOPPER V0511-43740 | 1 | $26.39 | |||
Showing 1 to 26 of 26 parts
