Kubota KVP30 130102 FLYWHEEL AND MAGNETO Parts Diagram
Exploded-view parts diagram "130102 FLYWHEEL AND MAGNETO" for the Kubota KVP30. 10 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | SPARK PLUG 12992-67710 | 1 | $7.71 | |||
| 010 | SPARK PLUG*** 12866-67710 | 1 | $21.68 | |||
| 020 | CAP, SPARK PLUG 12807-67720 | 1 | $26.38 | |||
| 020 | CAP, SPARK PLUG 13921-67720 | 1 | $6.41 | |||
| 030 | COMP,FLYWHEEL 12845-67040 Discontinued | 1 | $66.63 | |||
| 040 | IGNITER 12851-67050 Discontinued | 1 | $142.21 | |||
| 050 | FAN E3132-68023 Discontinued | 1 | $18.14 | |||
| 060 | BOLT 13801-91120 | 1 | $2.29 | |||
| 070 | KEY, WOODRUFF 05811-00416 12331-95230 | 1 | $2.99 | |||
| 080 | 33T, FLYWHEEL 12331-67350 | 1 | $15.91 | |||
Showing 1 to 10 of 10 parts
