Kubota AV2500-3Y-USA 100600 FAN COVER Parts Diagram
Exploded-view parts diagram "100600 FAN COVER" for the Kubota AV2500-3Y-USA. 8 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | COVER, ASSY FAN EG134-74040 Discontinued | 1 | $112.73 | |||
| 025 | LABEL EG134-88010 | 1 | $4.46 | |||
| 030 | BOLT 13641-74520 | 1 | $1.01 | |||
| 040 | COWLING, CYL HEA 12657-74480 | 1 | $31.90 | |||
| 040 | COWLING, CYL.HEA 12657-74483 | 1 | $32.85 | |||
| 050 | BOLT 13921-91040 | 1 | $1.75 | |||
| 060 | Bolt 01123-60814 01123-70814 | 1 | $0.99 | |||
| 070 | LABEL 18430-88310 18430-88312 Discontinued | 1 | $1.97 | |||
Showing 1 to 8 of 8 parts
